I bought this watch expecting a parts watch, closer inspection it’s actually a new old stock watch and I think I can bring it back to its former glory.

ServiceServiceService

Esa 9154 Service Manual Free

I will say that these ESA electronic balance wheel movements actually did have a decent window of time when they were relevant, with these 13 jewel versions being introduced in 1967 (and produced through 1970), while a later version with 7 jewels (ESA 9157 – 9159) was produced at least through the mid-70s.

Esa 9154 Service Manual Download

The original sales label still attached.Case back has the characteristic lid for changing the batteries.I eventually figure out how to open the case back, revealing the movement. I’m lucky as the battery has just started to leak and had not have time to cause any damage.Incredibly the watch starts ticking with a new battery.Dial is incredibly dirty and I have no idea how it could have accumulated.The date mechanism is very nicely made.The stem is on the other side of the movement and is connected via a conical gear down to the hour wheel.The circuit board removed from the movement, this unit will not go in the cleaning machine, the same goes for the balance wheel as it is magnetic and will attract particles in the fluid.Unlike a conventional mechanical movement the power to the gear train comes from the balance.Underneath the train bridge there is two springs to ensure that movement does not recoil.After cleaning the movement I started on the dial side.The date and setting mechanism back in place. The gear train back in place.Now the tricky part! To get the train bridge is place with the tension springs.The balance back in place.The Circuit board back in place.The dial cleans up very nice with water and soap.Case gets a light polish.Movement back in the caseThe Movement starts straight up when in contact with a battery.Amplitude is irrelevant, as I don’t know the lift angle, but I can time the movement.The case is composed of outer case, inner case, case back and a lid for the battery.I give the original NOS strap a generous amount of leather softener and I keep the label for fun, as it is more and more unusual to find this on 40+year watches.Now that is a transformation!I’m very happy how this turned out! This movement must have cost a fortune for ESA/ETA to develop and by the time it was put into production it was out of date, as the quartz revolution had just started.
